VMware ESXi: The Purpose-Built Bare Metal Hypervisor

0x00.安装或升级

ESXCLI使用Zip文件更新ESXi主机

1.下载

7.0
7.0

下载链接来源未知,请自行鉴别安全性

VMware vSphere Hypervisor(ESXi)脱机捆绑包
链接: VMware-ESXi-7.0.0-15843807-depot.zip
档案大小: 344 MB
MD5: d3e7d11daaa98d235694201b367dfdb2
SHA1: 84c27637f0f48f11f7638425c9e106d68c27f6fc

下完之后扔到存储上

2.ESXCLI

官方中文教程
官方中文教程

挂起全部虚拟机之后进入维护模式

1
2
3
4
[yuangezhizao@VM:~] vim-cmd hostsvc/maintenance_mode_enter
Operation timed out.
[yuangezhizao@VM:~] vim-cmd hostsvc/maintenance_mode_enter
[yuangezhizao@VM:~]
维护中
维护中

然后命令行升级,注意需要全路径

1
2
3
4
5
6
7
8
9
10
11
[yuangezhizao@VM:~] cd /vmfs/volumes/5d5d97d2-f9f4fe8f-7361-2c56dc945d15
[yuangezhizao@VM:/vmfs/volumes/5d5d97d2-f9f4fe8f-7361-2c56dc945d15] esxcli software vib update -d VMware-ESXi-7.0.0-15843807-depot.zip
[MetadataDownloadError]
Could not download from depot at zip:/var/log/vmware/VMware-ESXi-7.0.0-15843807-depot.zip?index.xml, skipping (('zip:/var/log/vmware/VMware-ESXi-7.0.0-15843807-depot.zip?index.xml', '', "Error extracting index.xml from /var/log/vmware/VMware-ESXi-7.0.0-15843807-depot.zip: [Errno 2] No such file or directory: '/var/log/vmware/VMware-ESXi-7.0.0-15843807-depot.zip'"))
url = zip:/var/log/vmware/VMware-ESXi-7.0.0-15843807-depot.zip?index.xml
Please refer to the log file for more details.
[yuangezhizao@VM:/vmfs/volumes/5d5d97d2-f9f4fe8f-7361-2c56dc945d15] esxcli software vib update -d /vmfs/volumes/5d5d97d2-f9f4fe8f-7361-2c56dc945d15/VMware-ESXi-7.0.0-15843807-depot.zip
[DependencyError]
VIB Realtek_bootbank_net55-r8168_8.045a-napi requires vmkapi_2_2_0_0, but the requirement cannot be satisfied within the ImageProfile.
VIB Realtek_bootbank_net55-r8168_8.045a-napi requires com.vmware.driverAPI-9.2.2.0, but the requirement cannot be satisfied within the ImageProfile.
Please refer to the log file for more details.

结果有冲突,没错(螃蟹网卡)还未支持?

Dependencies and Restrictions
Dependencies and Restrictions

然后去看下网卡信息

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
[yuangezhizao@VM:~] esxcli network nic list
Name PCI Device Driver Admin Status Link Status Speed Duplex MAC Address MTU Description
------ ------------ ------ ------------ ----------- ----- ------ ----------------- ---- -------------------------------------------------
vmnic0 0000:07:00.0 igbn Up Up 1000 Full 00:13:32:08:f7:d4 1500 Intel Corporation I211 Gigabit Network Connection
vmnic1 0000:09:00.0 igbn Up Up 1000 Full 00:13:32:08:f7:d5 1500 Intel Corporation I211 Gigabit Network Connection
[yuangezhizao@VM:~] esxcli network nic get -n vmnic0
Advertised Auto Negotiation: true
Advertised Link Modes: Auto, 1000BaseT/Full, 100BaseT/Full, 10BaseT/Full
Auto Negotiation: true
Cable Type: Twisted Pair
Current Message Level: 0
Driver Info:
Bus Info: 0000:07:00:0
Driver: igbn
Firmware Version: 0.6-5
Version: 0.1.1.0
Link Detected: true
Link Status: Up
Name: vmnic0
PHYAddress: 0
Pause Autonegotiate: false
Pause RX: false
Pause TX: false
Supported Ports: TP
Supports Auto Negotiation: true
Supports Pause: false
Supports Wakeon: true
Transceiver: internal
Virtual Address: 00:50:56:50:0a:c0
Wakeon: MagicPacket(tm)

现在用的是Intel的网卡哈哈哈,看下全部VIB列表

点击此处 ← 查看终端
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
[yuangezhizao@VM:~] esxcli software vib list
Name Version Vendor Acceptance Level Install Date
----------------------------- ------------------------------------ ------- ------------------ ------------
net55-r8168 8.045a-napi Realtek CommunitySupported 2019-12-27
ata-libata-92 3.00.9.2-16vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
ata-pata-amd 0.3.10-3vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
ata-pata-atiixp 0.4.6-4vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
ata-pata-cmd64x 0.2.5-3vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
ata-pata-hpt3x2n 0.3.4-3vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
ata-pata-pdc2027x 1.0-3vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
ata-pata-serverworks 0.4.3-3vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
ata-pata-sil680 0.4.8-3vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
ata-pata-via 0.3.3-2vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
block-cciss 3.6.14-10vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
bnxtnet 20.6.101.7-24vmw.670.3.73.14320388 VMW VMwareCertified 2019-12-27
bnxtroce 20.6.101.0-20vmw.670.1.28.10302608 VMW VMwareCertified 2019-12-27
brcmfcoe 11.4.1078.25-14vmw.670.3.73.14320388 VMW VMwareCertified 2019-12-27
char-random 1.0-3vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
ehci-ehci-hcd 1.0-4vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
elxiscsi 11.4.1174.0-2vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
elxnet 11.4.1097.0-5vmw.670.3.73.14320388 VMW VMwareCertified 2019-12-27
hid-hid 1.0-3vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
i40en 1.8.1.9-2vmw.670.3.73.14320388 VMW VMwareCertified 2019-12-27
iavmd 1.2.0.1011-2vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
igbn 0.1.1.0-5vmw.670.3.73.14320388 VMW VMwareCertified 2019-12-27
ima-qla4xxx 2.02.18-1vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
ipmi-ipmi-devintf 39.1-5vmw.670.1.28.10302608 VMW VMwareCertified 2019-12-27
ipmi-ipmi-msghandler 39.1-5vmw.670.1.28.10302608 VMW VMwareCertified 2019-12-27
ipmi-ipmi-si-drv 39.1-5vmw.670.1.28.10302608 VMW VMwareCertified 2019-12-27
iser 1.0.0.0-1vmw.670.1.28.10302608 VMW VMwareCertified 2019-12-27
ixgben 1.7.1.16-1vmw.670.3.73.14320388 VMW VMwareCertified 2019-12-27
lpfc 11.4.33.25-14vmw.670.3.73.14320388 VMW VMwareCertified 2019-12-27
lpnic 11.4.59.0-1vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
lsi-mr3 7.708.07.00-3vmw.670.3.73.14320388 VMW VMwareCertified 2019-12-27
lsi-msgpt2 20.00.06.00-2vmw.670.3.73.14320388 VMW VMwareCertified 2019-12-27
lsi-msgpt35 09.00.00.00-5vmw.670.3.73.14320388 VMW VMwareCertified 2019-12-27
lsi-msgpt3 17.00.02.00-1vmw.670.3.73.14320388 VMW VMwareCertified 2019-12-27
misc-cnic-register 1.78.75.v60.7-1vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
misc-drivers 6.7.0-2.48.13006603 VMW VMwareCertified 2019-12-27
mtip32xx-native 3.9.8-1vmw.670.1.28.10302608 VMW VMwareCertified 2019-12-27
ne1000 0.8.4-2vmw.670.2.48.13006603 VMW VMwareCertified 2019-12-27
nenic 1.0.29.0-1vmw.670.3.73.14320388 VMW VMwareCertified 2019-12-27
net-bnx2 2.2.4f.v60.10-2vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
net-bnx2x 1.78.80.v60.12-2vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
net-cdc-ether 1.0-3vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
net-cnic 1.78.76.v60.13-2vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
net-e1000 8.0.3.1-5vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
net-e1000e 3.2.2.1-2vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
net-enic 2.1.2.38-2vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
net-fcoe 1.0.29.9.3-7vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
net-forcedeth 0.61-2vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
net-igb 5.0.5.1.1-5vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
net-ixgbe 3.7.13.7.14iov-20vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
net-libfcoe-92 1.0.24.9.4-8vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
net-mlx4-core 1.9.7.0-1vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
net-mlx4-en 1.9.7.0-1vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
net-nx-nic 5.0.621-5vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
net-tg3 3.131d.v60.4-2vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
net-usbnet 1.0-3vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
net-vmxnet3 1.1.3.0-3vmw.670.3.89.15160138 VMW VMwareCertified 2019-12-27
nfnic 4.0.0.29-0vmw.670.3.73.14320388 VMW VMwareCertified 2019-12-27
nhpsa 2.0.22-3vmw.670.1.28.10302608 VMW VMwareCertified 2019-12-27
nmlx4-core 3.17.13.1-1vmw.670.2.48.13006603 VMW VMwareCertified 2019-12-27
nmlx4-en 3.17.13.1-1vmw.670.2.48.13006603 VMW VMwareCertified 2019-12-27
nmlx4-rdma 3.17.13.1-1vmw.670.2.48.13006603 VMW VMwareCertified 2019-12-27
nmlx5-core 4.17.13.1-1vmw.670.3.73.14320388 VMW VMwareCertified 2019-12-27
nmlx5-rdma 4.17.13.1-1vmw.670.2.48.13006603 VMW VMwareCertified 2019-12-27
ntg3 4.1.3.2-1vmw.670.1.28.10302608 VMW VMwareCertified 2019-12-27
nvme 1.2.2.28-1vmw.670.3.73.14320388 VMW VMwareCertified 2019-12-27
nvmxnet3-ens 2.0.0.21-1vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
nvmxnet3 2.0.0.29-1vmw.670.1.28.10302608 VMW VMwareCertified 2019-12-27
ohci-usb-ohci 1.0-3vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
pvscsi 0.1-2vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
qcnic 1.0.2.0.4-1vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
qedentv 2.0.6.4-10vmw.670.1.28.10302608 VMW VMwareCertified 2019-12-27
qfle3 1.0.50.11-9vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
qfle3f 1.0.25.0.2-14vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
qfle3i 1.0.2.3.9-3vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
qflge 1.1.0.11-1vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
sata-ahci 3.0-26vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
sata-ata-piix 2.12-10vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
sata-sata-nv 3.5-4vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
sata-sata-promise 2.12-3vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
sata-sata-sil24 1.1-1vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
sata-sata-sil 2.3-4vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
sata-sata-svw 2.3-3vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
scsi-aacraid 1.1.5.1-9vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
scsi-adp94xx 1.0.8.12-6vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
scsi-aic79xx 3.1-6vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
scsi-bnx2fc 1.78.78.v60.8-1vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
scsi-bnx2i 2.78.76.v60.8-1vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
scsi-fnic 1.5.0.45-3vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
scsi-hpsa 6.0.0.84-3vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
scsi-ips 7.12.05-4vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
scsi-iscsi-linux-92 1.0.0.2-3vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
scsi-libfc-92 1.0.40.9.3-5vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
scsi-megaraid-mbox 2.20.5.1-6vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
scsi-megaraid-sas 6.603.55.00-2vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
scsi-megaraid2 2.00.4-9vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
scsi-mpt2sas 19.00.00.00-2vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
scsi-mptsas 4.23.01.00-10vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
scsi-mptspi 4.23.01.00-10vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
scsi-qla4xxx 5.01.03.2-7vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
sfvmk 1.0.0.1003-6vmw.670.3.73.14320388 VMW VMwareCertified 2019-12-27
shim-iscsi-linux-9-2-1-0 6.7.0-0.0.8169922 VMW VMwareCertified 2019-12-27
shim-iscsi-linux-9-2-2-0 6.7.0-0.0.8169922 VMW VMwareCertified 2019-12-27
shim-libata-9-2-1-0 6.7.0-0.0.8169922 VMW VMwareCertified 2019-12-27
shim-libata-9-2-2-0 6.7.0-0.0.8169922 VMW VMwareCertified 2019-12-27
shim-libfc-9-2-1-0 6.7.0-0.0.8169922 VMW VMwareCertified 2019-12-27
shim-libfc-9-2-2-0 6.7.0-0.0.8169922 VMW VMwareCertified 2019-12-27
shim-libfcoe-9-2-1-0 6.7.0-0.0.8169922 VMW VMwareCertified 2019-12-27
shim-libfcoe-9-2-2-0 6.7.0-0.0.8169922 VMW VMwareCertified 2019-12-27
shim-vmklinux-9-2-1-0 6.7.0-0.0.8169922 VMW VMwareCertified 2019-12-27
shim-vmklinux-9-2-2-0 6.7.0-0.0.8169922 VMW VMwareCertified 2019-12-27
shim-vmklinux-9-2-3-0 6.7.0-0.0.8169922 VMW VMwareCertified 2019-12-27
smartpqi 1.0.1.553-28vmw.670.3.73.14320388 VMW VMwareCertified 2019-12-27
uhci-usb-uhci 1.0-3vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
usb-storage-usb-storage 1.0-3vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
usbcore-usb 1.0-3vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
vmkata 0.1-1vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
vmkfcoe 1.0.0.1-1vmw.670.1.28.10302608 VMW VMwareCertified 2019-12-27
vmkplexer-vmkplexer 6.7.0-0.0.8169922 VMW VMwareCertified 2019-12-27
vmkusb 0.1-1vmw.670.3.89.15160138 VMW VMwareCertified 2019-12-27
vmw-ahci 1.2.8-1vmw.670.3.73.14320388 VMW VMwareCertified 2019-12-27
xhci-xhci 1.0-3vmw.670.0.0.8169922 VMW VMwareCertified 2019-12-27
cpu-microcode 6.7.0-3.77.15018017 VMware VMwareCertified 2019-12-27
elx-esx-libelxima.so 11.4.1184.2-3.89.15160138 VMware VMwareCertified 2019-12-27
esx-base 6.7.0-3.89.15160138 VMware VMwareCertified 2019-12-27
esx-dvfilter-generic-fastpath 6.7.0-0.0.8169922 VMware VMwareCertified 2019-12-27
esx-ui 1.33.4-14093553 VMware VMwareCertified 2019-12-27
esx-update 6.7.0-3.89.15160138 VMware VMwareCertified 2019-12-27
esx-xserver 6.7.0-3.73.14320388 VMware VMwareCertified 2019-12-27
lsu-hp-hpsa-plugin 2.0.0-16vmw.670.1.28.10302608 VMware VMwareCertified 2019-12-27
lsu-intel-vmd-plugin 1.0.0-2vmw.670.1.28.10302608 VMware VMwareCertified 2019-12-27
lsu-lsi-drivers-plugin 1.0.0-1vmw.670.2.48.13006603 VMware VMwareCertified 2019-12-27
lsu-lsi-lsi-mr3-plugin 1.0.0-13vmw.670.1.28.10302608 VMware VMwareCertified 2019-12-27
lsu-lsi-lsi-msgpt3-plugin 1.0.0-9vmw.670.2.48.13006603 VMware VMwareCertified 2019-12-27
lsu-lsi-megaraid-sas-plugin 1.0.0-9vmw.670.0.0.8169922 VMware VMwareCertified 2019-12-27
lsu-lsi-mpt2sas-plugin 2.0.0-7vmw.670.0.0.8169922 VMware VMwareCertified 2019-12-27
lsu-smartpqi-plugin 1.0.0-3vmw.670.1.28.10302608 VMware VMwareCertified 2019-12-27
native-misc-drivers 6.7.0-3.89.15160138 VMware VMwareCertified 2019-12-27
qlnativefc 3.1.8.0-5vmw.670.3.73.14320388 VMware VMwareCertified 2019-12-27
rste 2.0.2.0088-7vmw.670.0.0.8169922 VMware VMwareCertified 2019-12-27
vmware-esx-esxcli-nvme-plugin 1.2.0.36-2.48.13006603 VMware VMwareCertified 2019-12-27
vsan 6.7.0-3.89.14840357 VMware VMwareCertified 2019-12-27
vsanhealth 6.7.0-3.89.14840358 VMware VMwareCertified 2019-12-27
tools-light 11.0.1.14773994-15160134 VMware VMwareCertified 2019-12-27

不难看出Intel用的是igbn这个库,于是大胆移除net55-r8168

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
[yuangezhizao@VM:~] esxcli software vib get -n net55-r8168
Realtek_bootbank_net55-r8168_8.045a-napi
Name: net55-r8168
Version: 8.045a-napi
Type: bootbank
Vendor: Realtek
Acceptance Level: CommunitySupported
Summary: Driver for Realtek 8111/8168
Description: Recent driver for Realtek 8111/8168. Based on original Realtek drivers
ReferenceURLs: kb|https://vibsdepot.v-front.de/wiki/index.php/Net55-r8168
Creation Date: 2018-04-16
Depends: vmkapi_2_2_0_0, com.vmware.driverAPI-9.2.2.0
Conflicts: net51-drivers
Replaces: net-r8168
Provides:
Maintenance Mode Required: True
Hardware Platforms Required:
Live Install Allowed: False
Live Remove Allowed: False
Stateless Ready: True
Overlay: False
Tags: driver, module
Payloads: net55-r8
[yuangezhizao@VM:~] esxcli software vib remove -n net55-r8168
Removal Result
Message: The update completed successfully, but the system needs to be rebooted for the changes to be effective.
Reboot Required: true
VIBs Installed:
VIBs Removed: Realtek_bootbank_net55-r8168_8.045a-napi
VIBs Skipped:

立即重新升级

1
2
3
4
5
6
7
8
[yuangezhizao@VM:~] esxcli software vib update -d /vmfs/volumes/5d5d97d2-f9f4fe8f-7361-2c56dc945d15/VMware-ESXi-7.0.0
-15843807-depot.zip
Installation Result
Message: The update completed successfully, but the system needs to be rebooted for the changes to be effective.
Reboot Required: true
VIBs Installed: VMW_bootbank_bnxtnet_216.0.50.0-4vmw.700.1.0.15843807, VMW_bootbank_bnxtroce_216.0.58.0-1vmw.700.1.0.15843807, VMW_bootbank_brcmfcoe_12.0.1500.0-1vmw.700.1.0.15843807, VMW_bootbank_elxiscsi_12.0.1200.0-1vmw.700.1.0.15843807, VMW_bootbank_elxnet_12.0.1250.0-5vmw.700.1.0.15843807, VMW_bootbank_i40en_1.8.1.16-1vmw.700.1.0.15843807, VMW_bootbank_iavmd_2.0.0.1055-3vmw.700.1.0.15843807, VMW_bootbank_igbn_0.1.1.0-6vmw.700.1.0.15843807, VMW_bootbank_iser_1.1.0.0-1vmw.700.1.0.15843807, VMW_bootbank_ixgben_1.7.1.26-1vmw.700.1.0.15843807, VMW_bootbank_lpfc_12.4.293.3-5vmw.700.1.0.15843807, VMW_bootbank_lpnic_11.4.62.0-1vmw.700.1.0.15843807, VMW_bootbank_lsi-mr3_7.712.50.00-1vmw.700.1.0.15843807, VMW_bootbank_lsi-msgpt2_20.00.06.00-2vmw.700.1.0.15843807, VMW_bootbank_lsi-msgpt35_13.00.12.00-1vmw.700.1.0.15843807, VMW_bootbank_lsi-msgpt3_17.00.10.00-1vmw.700.1.0.15843807, VMW_bootbank_mtip32xx-native_3.9.8-1vmw.700.1.0.15843807, VMW_bootbank_ne1000_0.8.4-10vmw.700.1.0.15843807, VMW_bootbank_nenic_1.0.29.0-1vmw.700.1.0.15843807, VMW_bootbank_nfnic_4.0.0.44-1vmw.700.1.0.15843807, VMW_bootbank_nhpsa_2.0.50-1vmw.700.1.0.15843807, VMW_bootbank_nmlx4-core_3.19.16.7-1vmw.700.1.0.15843807, VMW_bootbank_nmlx4-en_3.19.16.7-1vmw.700.1.0.15843807, VMW_bootbank_nmlx4-rdma_3.19.16.7-1vmw.700.1.0.15843807, VMW_bootbank_nmlx5-core_4.19.16.7-1vmw.700.1.0.15843807, VMW_bootbank_nmlx5-rdma_4.19.16.7-1vmw.700.1.0.15843807, VMW_bootbank_ntg3_4.1.4.1-1vmw.700.1.0.15843807, VMW_bootbank_nvmxnet3-ens_2.0.0.22-1vmw.700.1.0.15843807, VMW_bootbank_nvmxnet3_2.0.0.30-1vmw.700.1.0.15843807, VMW_bootbank_pvscsi_0.1-2vmw.700.1.0.15843807, VMW_bootbank_qcnic_1.0.15.0-8vmw.700.1.0.15843807, VMW_bootbank_qedentv_3.12.1.0-23vmw.700.1.0.15843807, VMW_bootbank_qfle3_1.0.66.0-5vmw.700.1.0.15843807, VMW_bootbank_qfle3f_1.0.51.0-12vmw.700.1.0.15843807, VMW_bootbank_qfle3i_1.0.15.0-6vmw.700.1.0.15843807, VMW_bootbank_qflge_1.1.0.11-1vmw.700.1.0.15843807, VMW_bootbank_rste_2.0.2.0088-7vmw.700.1.0.15843807, VMW_bootbank_sfvmk_2.0.0.1004-3vmw.700.1.0.15843807, VMW_bootbank_smartpqi_1.0.4.3011-1vmw.700.1.0.15843807, VMW_bootbank_vmkata_0.1-1vmw.700.1.0.15843807, VMW_bootbank_vmkfcoe_1.0.0.2-1vmw.700.1.0.15843807, VMW_bootbank_vmkusb_0.1-1vmw.700.1.0.15843807, VMW_bootbank_vmw-ahci_1.3.9-1vmw.700.1.0.15843807, VMware_bootbank_cpu-microcode_7.0.0-1.0.15843807, VMware_bootbank_elx-esx-libelxima.so_12.0.1200.0-2vmw.700.1.0.15843807, VMware_bootbank_esx-base_7.0.0-1.0.15843807, VMware_bootbank_esx-dvfilter-generic-fastpath_7.0.0-1.0.15843807, VMware_bootbank_esx-ui_1.34.0-15603211, VMware_bootbank_esx-update_7.0.0-1.0.15843807, VMware_bootbank_esx-xserver_7.0.0-1.0.15843807, VMware_bootbank_lsuv2-hpv2-hpsa-plugin_1.0.0-2vmw.700.1.0.15843807, VMware_bootbank_lsuv2-intelv2-nvme-vmd-plugin_1.0.0-2vmw.700.1.0.15843807, VMware_bootbank_lsuv2-lsiv2-drivers-plugin_1.0.0-2vmw.700.1.0.15843807, VMware_bootbank_lsuv2-smartpqiv2-plugin_1.0.0-3vmw.700.1.0.15843807, VMware_bootbank_native-misc-drivers_7.0.0-1.0.15843807, VMware_bootbank_qlnativefc_4.0.1.0-3vmw.700.1.0.15843807, VMware_bootbank_vmware-esx-esxcli-nvme-plugin_1.2.0.37-1vmw.700.1.0.15843807, VMware_bootbank_vsan_7.0.0-1.0.15843807, VMware_bootbank_vsanhealth_7.0.0-1.0.15843807, VMware_locker_tools-light_11.0.5.15389592-15843807
VIBs Removed: VMW_bootbank_ata-libata-92_3.00.9.2-16vmw.670.0.0.8169922, VMW_bootbank_ata-pata-amd_0.3.10-3vmw.670.0.0.8169922, VMW_bootbank_ata-pata-atiixp_0.4.6-4vmw.670.0.0.8169922, VMW_bootbank_ata-pata-cmd64x_0.2.5-3vmw.670.0.0.8169922, VMW_bootbank_ata-pata-hpt3x2n_0.3.4-3vmw.670.0.0.8169922, VMW_bootbank_ata-pata-pdc2027x_1.0-3vmw.670.0.0.8169922, VMW_bootbank_ata-pata-serverworks_0.4.3-3vmw.670.0.0.8169922, VMW_bootbank_ata-pata-sil680_0.4.8-3vmw.670.0.0.8169922, VMW_bootbank_ata-pata-via_0.3.3-2vmw.670.0.0.8169922, VMW_bootbank_block-cciss_3.6.14-10vmw.670.0.0.8169922, VMW_bootbank_bnxtnet_20.6.101.7-24vmw.670.3.73.14320388, VMW_bootbank_bnxtroce_20.6.101.0-20vmw.670.1.28.10302608, VMW_bootbank_brcmfcoe_11.4.1078.25-14vmw.670.3.73.14320388, VMW_bootbank_char-random_1.0-3vmw.670.0.0.8169922, VMW_bootbank_ehci-ehci-hcd_1.0-4vmw.670.0.0.8169922, VMW_bootbank_elxiscsi_11.4.1174.0-2vmw.670.0.0.8169922, VMW_bootbank_elxnet_11.4.1097.0-5vmw.670.3.73.14320388, VMW_bootbank_hid-hid_1.0-3vmw.670.0.0.8169922, VMW_bootbank_i40en_1.8.1.9-2vmw.670.3.73.14320388, VMW_bootbank_iavmd_1.2.0.1011-2vmw.670.0.0.8169922, VMW_bootbank_igbn_0.1.1.0-5vmw.670.3.73.14320388, VMW_bootbank_ima-qla4xxx_2.02.18-1vmw.670.0.0.8169922, VMW_bootbank_ipmi-ipmi-devintf_39.1-5vmw.670.1.28.10302608, VMW_bootbank_ipmi-ipmi-msghandler_39.1-5vmw.670.1.28.10302608, VMW_bootbank_ipmi-ipmi-si-drv_39.1-5vmw.670.1.28.10302608, VMW_bootbank_iser_1.0.0.0-1vmw.670.1.28.10302608, VMW_bootbank_ixgben_1.7.1.16-1vmw.670.3.73.14320388, VMW_bootbank_lpfc_11.4.33.25-14vmw.670.3.73.14320388, VMW_bootbank_lpnic_11.4.59.0-1vmw.670.0.0.8169922, VMW_bootbank_lsi-mr3_7.708.07.00-3vmw.670.3.73.14320388, VMW_bootbank_lsi-msgpt2_20.00.06.00-2vmw.670.3.73.14320388, VMW_bootbank_lsi-msgpt35_09.00.00.00-5vmw.670.3.73.14320388, VMW_bootbank_lsi-msgpt3_17.00.02.00-1vmw.670.3.73.14320388, VMW_bootbank_misc-cnic-register_1.78.75.v60.7-1vmw.670.0.0.8169922, VMW_bootbank_misc-drivers_6.7.0-2.48.13006603, VMW_bootbank_mtip32xx-native_3.9.8-1vmw.670.1.28.10302608, VMW_bootbank_ne1000_0.8.4-2vmw.670.2.48.13006603, VMW_bootbank_nenic_1.0.29.0-1vmw.670.3.73.14320388, VMW_bootbank_net-bnx2_2.2.4f.v60.10-2vmw.670.0.0.8169922, VMW_bootbank_net-bnx2x_1.78.80.v60.12-2vmw.670.0.0.8169922, VMW_bootbank_net-cdc-ether_1.0-3vmw.670.0.0.8169922, VMW_bootbank_net-cnic_1.78.76.v60.13-2vmw.670.0.0.8169922, VMW_bootbank_net-e1000_8.0.3.1-5vmw.670.0.0.8169922, VMW_bootbank_net-e1000e_3.2.2.1-2vmw.670.0.0.8169922, VMW_bootbank_net-enic_2.1.2.38-2vmw.670.0.0.8169922, VMW_bootbank_net-fcoe_1.0.29.9.3-7vmw.670.0.0.8169922, VMW_bootbank_net-forcedeth_0.61-2vmw.670.0.0.8169922, VMW_bootbank_net-igb_5.0.5.1.1-5vmw.670.0.0.8169922, VMW_bootbank_net-ixgbe_3.7.13.7.14iov-20vmw.670.0.0.8169922, VMW_bootbank_net-libfcoe-92_1.0.24.9.4-8vmw.670.0.0.8169922, VMW_bootbank_net-mlx4-core_1.9.7.0-1vmw.670.0.0.8169922, VMW_bootbank_net-mlx4-en_1.9.7.0-1vmw.670.0.0.8169922, VMW_bootbank_net-nx-nic_5.0.621-5vmw.670.0.0.8169922, VMW_bootbank_net-tg3_3.131d.v60.4-2vmw.670.0.0.8169922, VMW_bootbank_net-usbnet_1.0-3vmw.670.0.0.8169922, VMW_bootbank_net-vmxnet3_1.1.3.0-3vmw.670.3.89.15160138, VMW_bootbank_nfnic_4.0.0.29-0vmw.670.3.73.14320388, VMW_bootbank_nhpsa_2.0.22-3vmw.670.1.28.10302608, VMW_bootbank_nmlx4-core_3.17.13.1-1vmw.670.2.48.13006603, VMW_bootbank_nmlx4-en_3.17.13.1-1vmw.670.2.48.13006603, VMW_bootbank_nmlx4-rdma_3.17.13.1-1vmw.670.2.48.13006603, VMW_bootbank_nmlx5-core_4.17.13.1-1vmw.670.3.73.14320388, VMW_bootbank_nmlx5-rdma_4.17.13.1-1vmw.670.2.48.13006603, VMW_bootbank_ntg3_4.1.3.2-1vmw.670.1.28.10302608, VMW_bootbank_nvme_1.2.2.28-1vmw.670.3.73.14320388, VMW_bootbank_nvmxnet3-ens_2.0.0.21-1vmw.670.0.0.8169922, VMW_bootbank_nvmxnet3_2.0.0.29-1vmw.670.1.28.10302608, VMW_bootbank_ohci-usb-ohci_1.0-3vmw.670.0.0.8169922, VMW_bootbank_pvscsi_0.1-2vmw.670.0.0.8169922, VMW_bootbank_qcnic_1.0.2.0.4-1vmw.670.0.0.8169922, VMW_bootbank_qedentv_2.0.6.4-10vmw.670.1.28.10302608, VMW_bootbank_qfle3_1.0.50.11-9vmw.670.0.0.8169922, VMW_bootbank_qfle3f_1.0.25.0.2-14vmw.670.0.0.8169922, VMW_bootbank_qfle3i_1.0.2.3.9-3vmw.670.0.0.8169922, VMW_bootbank_qflge_1.1.0.11-1vmw.670.0.0.8169922, VMW_bootbank_sata-ahci_3.0-26vmw.670.0.0.8169922, VMW_bootbank_sata-ata-piix_2.12-10vmw.670.0.0.8169922, VMW_bootbank_sata-sata-nv_3.5-4vmw.670.0.0.8169922, VMW_bootbank_sata-sata-promise_2.12-3vmw.670.0.0.8169922, VMW_bootbank_sata-sata-sil24_1.1-1vmw.670.0.0.8169922, VMW_bootbank_sata-sata-sil_2.3-4vmw.670.0.0.8169922, VMW_bootbank_sata-sata-svw_2.3-3vmw.670.0.0.8169922, VMW_bootbank_scsi-aacraid_1.1.5.1-9vmw.670.0.0.8169922, VMW_bootbank_scsi-adp94xx_1.0.8.12-6vmw.670.0.0.8169922, VMW_bootbank_scsi-aic79xx_3.1-6vmw.670.0.0.8169922, VMW_bootbank_scsi-bnx2fc_1.78.78.v60.8-1vmw.670.0.0.8169922, VMW_bootbank_scsi-bnx2i_2.78.76.v60.8-1vmw.670.0.0.8169922, VMW_bootbank_scsi-fnic_1.5.0.45-3vmw.670.0.0.8169922, VMW_bootbank_scsi-hpsa_6.0.0.84-3vmw.670.0.0.8169922, VMW_bootbank_scsi-ips_7.12.05-4vmw.670.0.0.8169922, VMW_bootbank_scsi-iscsi-linux-92_1.0.0.2-3vmw.670.0.0.8169922, VMW_bootbank_scsi-libfc-92_1.0.40.9.3-5vmw.670.0.0.8169922, VMW_bootbank_scsi-megaraid-mbox_2.20.5.1-6vmw.670.0.0.8169922, VMW_bootbank_scsi-megaraid-sas_6.603.55.00-2vmw.670.0.0.8169922, VMW_bootbank_scsi-megaraid2_2.00.4-9vmw.670.0.0.8169922, VMW_bootbank_scsi-mpt2sas_19.00.00.00-2vmw.670.0.0.8169922, VMW_bootbank_scsi-mptsas_4.23.01.00-10vmw.670.0.0.8169922, VMW_bootbank_scsi-mptspi_4.23.01.00-10vmw.670.0.0.8169922, VMW_bootbank_scsi-qla4xxx_5.01.03.2-7vmw.670.0.0.8169922, VMW_bootbank_sfvmk_1.0.0.1003-6vmw.670.3.73.14320388, VMW_bootbank_shim-iscsi-linux-9-2-1-0_6.7.0-0.0.8169922, VMW_bootbank_shim-iscsi-linux-9-2-2-0_6.7.0-0.0.8169922, VMW_bootbank_shim-libata-9-2-1-0_6.7.0-0.0.8169922, VMW_bootbank_shim-libata-9-2-2-0_6.7.0-0.0.8169922, VMW_bootbank_shim-libfc-9-2-1-0_6.7.0-0.0.8169922, VMW_bootbank_shim-libfc-9-2-2-0_6.7.0-0.0.8169922, VMW_bootbank_shim-libfcoe-9-2-1-0_6.7.0-0.0.8169922, VMW_bootbank_shim-libfcoe-9-2-2-0_6.7.0-0.0.8169922, VMW_bootbank_shim-vmklinux-9-2-1-0_6.7.0-0.0.8169922, VMW_bootbank_shim-vmklinux-9-2-2-0_6.7.0-0.0.8169922, VMW_bootbank_shim-vmklinux-9-2-3-0_6.7.0-0.0.8169922, VMW_bootbank_smartpqi_1.0.1.553-28vmw.670.3.73.14320388, VMW_bootbank_uhci-usb-uhci_1.0-3vmw.670.0.0.8169922, VMW_bootbank_usb-storage-usb-storage_1.0-3vmw.670.0.0.8169922, VMW_bootbank_usbcore-usb_1.0-3vmw.670.0.0.8169922, VMW_bootbank_vmkata_0.1-1vmw.670.0.0.8169922, VMW_bootbank_vmkfcoe_1.0.0.1-1vmw.670.1.28.10302608, VMW_bootbank_vmkplexer-vmkplexer_6.7.0-0.0.8169922, VMW_bootbank_vmkusb_0.1-1vmw.670.3.89.15160138, VMW_bootbank_vmw-ahci_1.2.8-1vmw.670.3.73.14320388, VMW_bootbank_xhci-xhci_1.0-3vmw.670.0.0.8169922, VMware_bootbank_cpu-microcode_6.7.0-3.77.15018017, VMware_bootbank_elx-esx-libelxima.so_11.4.1184.2-3.89.15160138, VMware_bootbank_esx-base_6.7.0-3.89.15160138, VMware_bootbank_esx-dvfilter-generic-fastpath_6.7.0-0.0.8169922, VMware_bootbank_esx-ui_1.33.4-14093553, VMware_bootbank_esx-update_6.7.0-3.89.15160138, VMware_bootbank_esx-xserver_6.7.0-3.73.14320388, VMware_bootbank_lsu-hp-hpsa-plugin_2.0.0-16vmw.670.1.28.10302608, VMware_bootbank_lsu-intel-vmd-plugin_1.0.0-2vmw.670.1.28.10302608, VMware_bootbank_lsu-lsi-drivers-plugin_1.0.0-1vmw.670.2.48.13006603, VMware_bootbank_lsu-lsi-lsi-mr3-plugin_1.0.0-13vmw.670.1.28.10302608, VMware_bootbank_lsu-lsi-lsi-msgpt3-plugin_1.0.0-9vmw.670.2.48.13006603, VMware_bootbank_lsu-lsi-megaraid-sas-plugin_1.0.0-9vmw.670.0.0.8169922, VMware_bootbank_lsu-lsi-mpt2sas-plugin_2.0.0-7vmw.670.0.0.8169922, VMware_bootbank_lsu-smartpqi-plugin_1.0.0-3vmw.670.1.28.10302608, VMware_bootbank_native-misc-drivers_6.7.0-3.89.15160138, VMware_bootbank_qlnativefc_3.1.8.0-5vmw.670.3.73.14320388, VMware_bootbank_rste_2.0.2.0088-7vmw.670.0.0.8169922, VMware_bootbank_vmware-esx-esxcli-nvme-plugin_1.2.0.36-2.48.13006603, VMware_bootbank_vsan_6.7.0-3.89.14840357, VMware_bootbank_vsanhealth_6.7.0-3.89.14840358, VMware_locker_tools-light_11.0.1.14773994-15160134
VIBs Skipped: VMW_bootbank_brcmnvmefc_12.4.293.2-3vmw.700.1.0.15843807, VMW_bootbank_i40iwn_1.1.2.5-1vmw.700.1.0.15843807, VMW_bootbank_nvme-pcie_1.2.2.13-1vmw.700.1.0.15843807, VMW_bootbank_nvmerdma_1.0.0.0-1vmw.700.1.0.15843807, VMW_bootbank_qedrntv_3.12.1.2-12vmw.700.1.0.15843807, VMware_bootbank_crx_7.0.0-1.0.15843807, VMware_bootbank_loadesx_7.0.0-1.0.15843807, VMware_bootbank_lsuv2-nvme-pcie-plugin_1.0.0-1vmw.700.1.0.15843807, VMware_bootbank_lsuv2-oem-dell-plugin_1.0.0-1vmw.700.1.0.15843807, VMware_bootbank_lsuv2-oem-hp-plugin_1.0.0-1vmw.700.1.0.15843807, VMware_bootbank_lsuv2-oem-lenovo-plugin_1.0.0-1vmw.700.1.0.15843807, VMware_bootbank_vdfs_7.0.0-1.0.15843807

重启

1
2
3
4
5
6
7
8
9
[yuangezhizao@VM:~] reboot
[yuangezhizao@VM:~] Connection closing...Socket close.

Connection closed by foreign host.

Disconnected from remote host(ESXi) at 01:46:40.

Type `help' to learn how to use Xshell prompt.
[D:\~]$

开机之后重新查看列表确信升级完成,退出维护模式

点击此处 ← 查看终端
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
Host 'esxi.yuangezhizao.cn' resolved to 192.168.25.249.
Connecting to 192.168.25.249:22...
Connection established.
To escape to local shell, press 'Ctrl+Alt+]'.

The time and date of this login have been sent to the system logs.

WARNING:
All commands run on the ESXi shell are logged and may be included in
support bundles. Do not provide passwords directly on the command line.
Most tools can prompt for secrets or accept them from standard input.

VMware offers supported, powerful system administration tools. Please
see www.vmware.com/go/sysadmintools for details.

The ESXi Shell can be disabled by an administrative user. See the
vSphere Security documentation for more information.
[yuangezhizao@VM:~] esxcli software vib list
Name Version Vendor Acceptance Level Install Date
----------------------------- --------------------------------- ------ ---------------- ------------
bnxtnet 216.0.50.0-4vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
bnxtroce 216.0.58.0-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
brcmfcoe 12.0.1500.0-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
elxiscsi 12.0.1200.0-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
elxnet 12.0.1250.0-5vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
i40en 1.8.1.16-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
iavmd 2.0.0.1055-3vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
igbn 0.1.1.0-6vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
iser 1.1.0.0-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
ixgben 1.7.1.26-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
lpfc 12.4.293.3-5vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
lpnic 11.4.62.0-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
lsi-mr3 7.712.50.00-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
lsi-msgpt2 20.00.06.00-2vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
lsi-msgpt35 13.00.12.00-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
lsi-msgpt3 17.00.10.00-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
mtip32xx-native 3.9.8-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
ne1000 0.8.4-10vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
nenic 1.0.29.0-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
nfnic 4.0.0.44-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
nhpsa 2.0.50-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
nmlx4-core 3.19.16.7-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
nmlx4-en 3.19.16.7-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
nmlx4-rdma 3.19.16.7-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
nmlx5-core 4.19.16.7-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
nmlx5-rdma 4.19.16.7-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
ntg3 4.1.4.1-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
nvmxnet3-ens 2.0.0.22-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
nvmxnet3 2.0.0.30-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
pvscsi 0.1-2vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
qcnic 1.0.15.0-8vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
qedentv 3.12.1.0-23vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
qfle3 1.0.66.0-5vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
qfle3f 1.0.51.0-12vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
qfle3i 1.0.15.0-6vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
qflge 1.1.0.11-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
rste 2.0.2.0088-7vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
sfvmk 2.0.0.1004-3vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
smartpqi 1.0.4.3011-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
vmkata 0.1-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
vmkfcoe 1.0.0.2-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
vmkusb 0.1-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
vmw-ahci 1.3.9-1vmw.700.1.0.15843807 VMW VMwareCertified 2020-04-03
cpu-microcode 7.0.0-1.0.15843807 VMware VMwareCertified 2020-04-03
elx-esx-libelxima.so 12.0.1200.0-2vmw.700.1.0.15843807 VMware VMwareCertified 2020-04-03
esx-base 7.0.0-1.0.15843807 VMware VMwareCertified 2020-04-03
esx-dvfilter-generic-fastpath 7.0.0-1.0.15843807 VMware VMwareCertified 2020-04-03
esx-ui 1.34.0-15603211 VMware VMwareCertified 2020-04-03
esx-update 7.0.0-1.0.15843807 VMware VMwareCertified 2020-04-03
esx-xserver 7.0.0-1.0.15843807 VMware VMwareCertified 2020-04-03
lsuv2-hpv2-hpsa-plugin 1.0.0-2vmw.700.1.0.15843807 VMware VMwareCertified 2020-04-03
lsuv2-intelv2-nvme-vmd-plugin 1.0.0-2vmw.700.1.0.15843807 VMware VMwareCertified 2020-04-03
lsuv2-lsiv2-drivers-plugin 1.0.0-2vmw.700.1.0.15843807 VMware VMwareCertified 2020-04-03
lsuv2-smartpqiv2-plugin 1.0.0-3vmw.700.1.0.15843807 VMware VMwareCertified 2020-04-03
native-misc-drivers 7.0.0-1.0.15843807 VMware VMwareCertified 2020-04-03
qlnativefc 4.0.1.0-3vmw.700.1.0.15843807 VMware VMwareCertified 2020-04-03
vmware-esx-esxcli-nvme-plugin 1.2.0.37-1vmw.700.1.0.15843807 VMware VMwareCertified 2020-04-03
vsan 7.0.0-1.0.15843807 VMware VMwareCertified 2020-04-03
vsanhealth 7.0.0-1.0.15843807 VMware VMwareCertified 2020-04-03
tools-light 11.0.5.15389592-15843807 VMware VMwareCertified 2020-04-03
[yuangezhizao@VM:~] vim-cmd hostsvc/maintenance_mode_exit
[yuangezhizao@VM:~]

最后分配个许可证就搞定了

7.0.0 (Build 15843807)
7.0.0 (Build 15843807)
JJ2WR-25L9P-H71A8-6J20P-C0K3F
JJ2WR-25L9P-H71A8-6J20P-C0K3F

封装含有Realtek 8168网卡驱动的离线包

1.PowerShell大法

设置PowerShell执行策略:Set-ExecutionPolicy -ExecutionPolicy RemoteSigned
安装VMware PowerCLI模块:Install-Module -Name VMware.PowerCLI
然后竟然炸了?

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
Microsoft Windows [版本 10.0.17763.914]
(c) 2018 Microsoft Corporation。保留所有权利。

C:\Windows\system32>ps
'ps' 不是内部或外部命令,也不是可运行的程序
或批处理文件。

C:\Windows\system32>powershell
Windows PowerShell
版权所有 (C) Microsoft Corporation。保留所有权利。

PS C:\Windows\system32> Set-ExecutionPolicy -ExecutionPolicy RemoteSigned
PS C:\Windows\system32> Install-Module -Name VMware.PowerCLI -Scope AllUsers

需要使用 NuGet 提供程序来继续操作
PowerShellGet 需要使用 NuGet 提供程序“2.8.5.201”或更高版本来与基于 NuGet 的存储库交互。必须在“C:\Program
Files\PackageManagement\ProviderAssemblies”或“C:\Users\yuangezhizao\AppData\Local\PackageManagement\ProviderAssemblie
s”中提供 NuGet 提供程序。也可以通过运行 'Install-PackageProvider -Name NuGet -MinimumVersion 2.8.5.201 -Force' 安装
NuGet 提供程序。是否要让 PowerShellGet 立即安装并导入 NuGet 提供程序?
[Y] 是(Y) [N] 否(N) [S] 暂停(S) [?] 帮助 (默认值为“Y”): Y
PackageManagement\Install-Package : 找不到与指定的搜索条件和程序包名称“VMware.PowerCLI”匹配的项目。请尝试使用 Get-PSR
epository 查看所有可用的注册程序包源。
所在位置 C:\Program Files\WindowsPowerShell\Modules\PowerShellGet\1.0.0.1\PSModule.psm1:1809 字符: 21
+ ... $null = PackageManagement\Install-Package @PSBoundParameters
+ ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
+ CategoryInfo : ObjectNotFound: (Microsoft.Power....InstallPackage:InstallPackage) [Install-Package], Ex
ception
+ FullyQualifiedErrorId : NoMatchFoundForCriteria,Microsoft.PowerShell.PackageManagement.Cmdlets.InstallPackage

PS C:\Windows\system32> Install-Module -Name VMware.PowerCLI -Scope AllUsers
PackageManagement\Install-Package : 找不到与指定的搜索条件和程序包名称“VMware.PowerCLI”匹配的项目。请尝试使用 Get-PSR
epository 查看所有可用的注册程序包源。
所在位置 C:\Program Files\WindowsPowerShell\Modules\PowerShellGet\1.0.0.1\PSModule.psm1:1809 字符: 21
+ ... $null = PackageManagement\Install-Package @PSBoundParameters
+ ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
+ CategoryInfo : ObjectNotFound: (Microsoft.Power....InstallPackage:InstallPackage) [Install-Package], Ex
ception
+ FullyQualifiedErrorId : NoMatchFoundForCriteria,Microsoft.PowerShell.PackageManagement.Cmdlets.InstallPackage

PS C:\Windows\system32>

只好去官网手动下载安装

最新 6.5.4 ?
最新 6.5.4 ?
网奇慢,好久才进到这个页面
网奇慢,好久才进到这个页面

翻了一大圈,才看到没有新版本下载地址的原因?

因为这玩楞会自动升级
因为这玩楞会自动升级

以及404的可能性之一

也就是说网炸了?
也就是说网炸了?
草

最终只好离线安装,然后就出现了如下的一幕

11.5.0
11.5.0
草 * 2
草 * 2
才看到原来这里写明了新版本会在新地址发布
才看到原来这里写明了新版本会在新地址发布

真·官网下载之后解压到模块目录下:C:\Windows\System32\WindowsPowerShell\v1.0\Modules顺手把VMware-PowerCLI-11.5.0-14912921重命名为了VMware-PowerCLI
2019-12-28 01:14:06终于找到了导入不能的解决方法,那就是解压完不要嵌套文件夹,要直接放在Modules目录下……
最后导入模块:Import-Module VMware.PowerCLI
附:
关闭CEIP(Customer Experience Improvement Program)Set-PowerCLIConfiguration -Scope User -ParticipateInCEIP $false
忽略证书验证:Set-PowerCLIConfiguration -InvalidCertificateAction Ignore

完美离线导入
完美离线导入
成功登录
成功登录
点击此处 ← 查看终端
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
PS C:\Users\yuangezhizao> $env:PSModulePath
D:\yuangezhizao\Documents\WindowsPowerShell\Modules;C:\Program Files\WindowsPowerShell\Modules;C:\Windows\system32\WindowsPowerShell\v1.0\Modules
PS C:\Users\yuangezhizao> Import-Module VMware.PowerCLI
警告: Please consider joining the VMware Customer Experience Improvement Program, so you can help us make PowerCLI a
better product. You can join using the following command:

Set-PowerCLIConfiguration -Scope User -ParticipateInCEIP $true

VMware's Customer Experience Improvement Program ("CEIP") provides VMware with information that enables VMware to
improve its products and services, to fix problems, and to advise you on how best to deploy and use our products. As
part of the CEIP, VMware collects technical information about your organization抯 use of VMware products and services
on a regular basis in association with your organization抯 VMware license key(s). This information does not personally
identify any individual.

For more details: type "help about_ceip" to see the related help article.

To disable this warning and set your preference use the following command and restart PowerShell:
Set-PowerCLIConfiguration -Scope User -ParticipateInCEIP $true or $false.
Welcome to VMware PowerCLI!

Log in to a vCenter Server or ESX host: Connect-VIServer
To find out what commands are available, type: Get-VICommand
To show searchable help for all PowerCLI commands: Get-PowerCLIHelp
Once you've connected, display all virtual machines: Get-VM
If you need more help, visit the PowerCLI community: Get-PowerCLICommunity

Copyright (C) VMware, Inc. All rights reserved.


PS C:\Users\yuangezhizao> Set-PowerCLIConfiguration -Scope User -ParticipateInCEIP $false

Perform operation?
Performing operation 'Update PowerCLI configuration.'?
[Y] 是(Y) [A] 全是(A) [N] 否(N) [L] 全否(L) [S] 暂停(S) [?] 帮助 (默认值为“Y”): Y

Scope ProxyPolicy DefaultVIServerMode InvalidCertificateAction DisplayDeprecationWarnings WebOperationTimeout
Seconds
----- ----------- ------------------- ------------------------ -------------------------- -------------------
Session UseSystemProxy Multiple Unset True 300
User
AllUsers


PS C:\Users\yuangezhizao> Set-PowerCLIConfiguration -InvalidCertificateAction Ignore

Perform operation?
Performing operation 'Update PowerCLI configuration.'?
[Y] 是(Y) [A] 全是(A) [N] 否(N) [L] 全否(L) [S] 暂停(S) [?] 帮助 (默认值为“Y”): Y

Scope ProxyPolicy DefaultVIServerMode InvalidCertificateAction DisplayDeprecationWarnings WebOperationTimeout
Seconds
----- ----------- ------------------- ------------------------ -------------------------- -------------------
Session UseSystemProxy Multiple Ignore True 300
User Ignore
AllUsers


PS C:\Users\yuangezhizao>

2.下载ESXi-Customizer-PS脚本

VMware Front Experience: ESXi-Customizer-PS
最新仍然是:Version 2.6.0 (2018-04-18)ESXi-Customizer-PS-v2.6.0.ps1

点击此处 ← 查看源码
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350
351
352
353
354
355
356
357
358
359
360
361
362
363
364
365
366
367
368
369
370
371
372
373
374
375
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
395
396
397
398
399
400
401
402
403
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
420
421
422
423
424
425
426
427
428
429
430
431
432
433
434
435
436
437
438
439
440
441
442
443
444
445
446
447
448
449
450
451
452
453
454
455
456
457
458
459
460
461
462
463
464
465
466
467
468
469
470
471
472
#############################################################################################################################
#
# ESXi-Customizer-PS.ps1 - a script to build a customized ESXi installation ISO using ImageBuilder
#
# Version: 2.6.0
# Author: Andreas Peetz (ESXi-Customizer-PS@v-front.de)
# Info/Tutorial: https://esxi-customizer-ps.v-front.de/
#
# License:
#
# This program is free software: you can redistribute it and/or modify it under the terms of the GNU General Public License
# as published by the Free Software Foundation, either version 3 of the License, or (at your option) any later version.
#
# This program is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty
# of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the GNU General Public License for more details.
#
# A copy of the GNU General Public License is available at http://www.gnu.org/licenses/.
#
#############################################################################################################################

param(
[string]$iZip = "",
[string]$pkgDir = "",
[string]$outDir = $(Split-Path $MyInvocation.MyCommand.Path),
[string]$ipname = "",
[string]$ipvendor = "",
[string]$ipdesc = "",
[switch]$vft = $false,
[string[]]$dpt = @(),
[string[]]$load = @(),
[string[]]$remove = @(),
[switch]$test = $false,
[switch]$sip = $false,
[switch]$nsc = $false,
[switch]$help = $false,
[switch]$ozip = $false,
[switch]$v50 = $false,
[switch]$v51 = $false,
[switch]$v55 = $false,
[switch]$v60 = $false,
[switch]$v65 = $false,
[switch]$v67 = $false,
[switch]$update = $false,
[string]$log = ($env:TEMP + "\ESXi-Customizer-PS-" + $PID + ".log")
)

# Constants
$ScriptName = "ESXi-Customizer-PS"
$ScriptVersion = "2.6.0"
$ScriptURL = "https://ESXi-Customizer-PS.v-front.de"

$AccLevel = @{"VMwareCertified" = 1; "VMwareAccepted" = 2; "PartnerSupported" = 3; "CommunitySupported" = 4}

# Online depot URLs
$vmwdepotURL = "https://hostupdate.vmware.com/software/VUM/PRODUCTION/main/vmw-depot-index.xml"
$vftdepotURL = "https://vibsdepot.v-front.de/"

# Function to update/add VIB package
function AddVIB2Profile($vib) {
$AddVersion = $vib.Version
$ExVersion = ($MyProfile.VibList | where { $_.Name -eq $vib.Name }).Version
if ($AccLevel[$vib.AcceptanceLevel.ToString()] -gt $AccLevel[$MyProfile.AcceptanceLevel.ToString()]) {
write-host -ForegroundColor Yellow -nonewline (" [New AcceptanceLevel: " + $vib.AcceptanceLevel + "]")
$MyProfile.AcceptanceLevel = $vib.AcceptanceLevel
}
If ($MyProfile.VibList -contains $vib) {
write-host -ForegroundColor Yellow " [IGNORED, already added]"
} else {
Add-EsxSoftwarePackage -SoftwarePackage $vib -Imageprofile $MyProfile -force -ErrorAction SilentlyContinue | Out-Null
if ($?) {
if ($ExVersion -eq $null) {
write-host -ForegroundColor Green " [OK, added]"
} else {
write-host -ForegroundColor Yellow (" [OK, replaced " + $ExVersion + "]")
}
} else {
write-host -ForegroundColor Red " [FAILED, invalid package?]"
}
}
}

# Function to test if entered string is numeric
function isNumeric ($x) {
$x2 = 0
$isNum = [System.Int32]::TryParse($x, [ref]$x2)
return $isNum
}

# Clean-up function
function cleanup() {
Stop-Transcript | Out-Null
if ($DefaultSoftwaredepots) { Remove-EsxSoftwaredepot $DefaultSoftwaredepots }
}

# Write info and help if requested
write-host ("`nThis is " + $ScriptName + " Version " + $ScriptVersion + " (visit " + $ScriptURL + " for more information!)")
if ($help) {
write-host "`nUsage:"
write-host " ESXi-Customizer-PS [-help] | [-izip <bundle> [-update]] [-sip] [-v67|-v65|-v60|-v55|-v51|-v50]"
write-host " [-ozip] [-pkgDir <dir>] [-outDir <dir>] [-vft] [-dpt depot1[,...]]"
write-host " [-load vib1[,...]] [-remove vib1[,...]] [-log <file>] [-ipname <name>]"
write-host " [-ipdesc <desc>] [-ipvendor <vendor>] [-nsc] [-test]"
write-host "`nOptional parameters:"
write-host " -help : display this help"
write-host " -izip <bundle> : use the VMware Offline bundle <bundle> as input instead of the Online depot"
write-host " -update : only with -izip, updates a local bundle with an ESXi patch from the VMware Online depot,"
write-host " combine this with the matching ESXi version selection switch"
write-host " -pkgDir <dir> : local directory of Offline bundles and/or VIB files to add (if any, no default)"
write-host " -ozip : output an Offline bundle instead of an installation ISO"
write-host " -outDir <dir> : directory to store the customized ISO or Offline bundle (the default is the"
write-host " script directory. If specified the log file will also be moved here.)"
write-host " -vft : connect the V-Front Online depot"
write-host " -dpt depot1[,...] : connect additional Online depots by URL or local Offline bundles by file name"
write-host " -load vib1[,...] : load additional packages from connected depots or Offline bundles"
write-host " -remove vib1[,...] : remove named VIB packages from the custom Imageprofile"
write-host " -sip : select an Imageprofile from the current list"
write-host " (default = auto-select latest available standard profile)"
write-host " -v67 | -v65 | -v60 |"
write-host " -v55 | -v51 | -v50 : Use only ESXi 6.7/6.5/6.0/5.5/5.1/5.0 Imageprofiles as input, ignore other versions"
write-host " -nsc : use -NoSignatureCheck with export"
write-host " -log <file> : Use custom log file <file>"
write-host " -ipname <name>"
write-host " -ipdesc <desc>"
write-host " -ipvendor <vendor> : provide a name, description and/or vendor for the customized"
write-host " Imageprofile (the default is derived from the cloned input Imageprofile)"
write-host " -test : skip package download and image build (for testing)`n"
exit
} else {
write-host "(Call with -help for instructions)"
if (!($PSBoundParameters.ContainsKey('log')) -and $PSBoundParameters.ContainsKey('outDir')) {
write-host ("`nTemporarily logging to " + $log + " ...")
} else {
write-host ("`nLogging to " + $log + " ...")
}
# Stop active transcript
try { Stop-Transcript | out-null } catch {}
# Start own transcript
try { Start-Transcript -Path $log -Force -Confirm:$false | Out-Null } catch {
write-host -ForegroundColor Red "`nFATAL ERROR: Log file cannot be opened. Bad file path or missing permission?`n"
exit
}
}

# The main try ...

$isModule = @{}
try {

# Check for and load required modules/snapins
foreach ($comp in "VMware.VimAutomation.Core", "VMware.ImageBuilder") {
if (Get-Module -ListAvailable -Name $comp -ErrorAction:SilentlyContinue) {
$isModule[$comp] = $true
if (!(Get-Module -Name $comp -ErrorAction:SilentlyContinue)) {
if (!(Import-Module -PassThru -Name $comp -ErrorAction:SilentlyContinue)) {
write-host -ForegroundColor Red "`nFATAL ERROR: Failed to import the $comp module!`n"
exit
}
}
} else {
$isModule[$comp] = $false
if (Get-PSSnapin -Registered -Name $comp -ErrorAction:SilentlyContinue) {
if (!(Get-PSSnapin -Name $comp -ErrorAction:SilentlyContinue)) {
if (!(Add-PSSnapin -PassThru -Name $comp -ErrorAction:SilentlyContinue)) {
write-host -ForegroundColor Red "`nFATAL ERROR: Failed to add the $comp snapin!`n"
exit
}
}
} else {
write-host -ForegroundColor Red "`nFATAL ERROR: $comp is not available as a module or snapin! It looks like there is no compatible version of PowerCLI installed!`n"
exit
}
}
}

# Parameter sanity check
if ( ($v50 -and ($v51 -or $v55 -or $v60 -or $v65 -or $v67)) -or ($v51 -and ($v55 -or $v60 -or $v65 -or $v67)) -or ($v55 -and ($v60 -or $v65 -or $v67)) -or ($v60 -and ($v65 -or $v67)) -or ($v65 -and $v67) ) {
write-host -ForegroundColor Yellow "`nWARNING: Multiple ESXi versions specified. Highest version will take precedence!"
}
if ($update -and ($izip -eq "")) {
write-host -ForegroundColor Red "`nFATAL ERROR: -update requires -izip!`n"
exit
}

# Check PowerShell and PowerCLI version
if (!(Test-Path variable:PSVersionTable)) {
write-host -ForegroundColor Red "`nFATAL ERROR: This script requires at least PowerShell version 2.0!`n"
exit
}
$psv = $PSVersionTable.PSVersion | select Major,Minor

if ($isModule["VMware.VimAutomation.Core"]) {
$pcvm = (get-module "VMware.VimAutomation.Core").Version
write-host ("`nRunning with PowerShell version " + $psv.Major + "." + $psv.Minor + " and VMware PowerCLI version " + $pcvm)
} else {
$pcv = Get-PowerCLIVersion | select major,minor,UserFriendlyVersion
write-host ("`nRunning with PowerShell version " + $psv.Major + "." + $psv.Minor + " and " + $pcv.UserFriendlyVersion)
if ( ($pcv.major -lt 5) -or (($pcv.major -eq 5) -and ($pcv.minor -eq 0)) ) {
write-host -ForegroundColor Red "`nFATAL ERROR: This script requires at least PowerCLI version 5.1 !`n"
exit
}
}

if ($update) {
# Try to add Offline bundle specified by -izip
write-host -nonewline "`nAdding Base Offline bundle $izip (to be updated)..."
if ($upddepot = Add-EsxSoftwaredepot $izip) {
write-host -ForegroundColor Green " [OK]"
} else {
write-host -ForegroundColor Red "`nFATAL ERROR: Cannot add Base Offline bundle!`n"
exit
}
if (!($CloneIP = Get-EsxImageprofile -Softwaredepot $upddepot)) {
write-host -ForegroundColor Red "`nFATAL ERROR: No Imageprofiles found in Base Offline bundle!`n"
exit
}
if ($CloneIP -is [system.array]) {
# Input Offline bundle includes multiple Imageprofiles. Pick only the latest standard profile:
write-host -ForegroundColor Yellow "Warning: Input Offline Bundle contains multiple Imageprofiles. Will pick the latest standard profile!"
$CloneIP = @( $CloneIP | Sort-Object -Descending -Property @{Expression={$_.Name.Substring(0,10)}},@{Expression={$_.CreationTime.Date}},Name )[0]
}
}

if (($izip -eq "") -or $update) {
# Connect the VMware ESXi base depot
write-host -nonewline "`nConnecting the VMware ESXi Online depot ..."
if ($basedepot = Add-EsxSoftwaredepot $vmwdepotURL) {
write-host -ForegroundColor Green " [OK]"
} else {
write-host -ForegroundColor Red "`nFATAL ERROR: Cannot add VMware ESXi Online depot. Please check your Internet connectivity and/or proxy settings!`n"
exit
}
} else {
# Try to add Offline bundle specified by -izip
write-host -nonewline "`nAdding base Offline bundle $izip ..."
if ($basedepot = Add-EsxSoftwaredepot $izip) {
write-host -ForegroundColor Green " [OK]"
} else {
write-host -ForegroundColor Red "`nFATAL ERROR: Cannot add VMware base Offline bundle!`n"
exit
}
}

if ($vft) {
# Connect the V-Front Online depot
write-host -nonewline "`nConnecting the V-Front Online depot ..."
if ($vftdepot = Add-EsxSoftwaredepot $vftdepotURL) {
write-host -ForegroundColor Green " [OK]"
} else {
write-host -ForegroundColor Red "`nFATAL ERROR: Cannot add the V-Front Online depot. Please check your internet connectivity and/or proxy settings!`n"
exit
}
}

if ($dpt -ne @()) {
# Connect additional depots (Online depot or Offline bundle)
$AddDpt = @()
for ($i=0; $i -lt $dpt.Length; $i++ ) {
write-host -nonewline ("`nConnecting additional depot " + $dpt[$i] + " ...")
if ($AddDpt += Add-EsxSoftwaredepot $dpt[$i]) {
write-host -ForegroundColor Green " [OK]"
} else {
write-host -ForegroundColor Red "`nFATAL ERROR: Cannot add Online depot or Offline bundle. In case of Online depot check your Internet"
write-host -ForegroundColor Red "connectivity and/or proxy settings! In case of Offline bundle check file name, format and permissions!`n"
exit
}
}

}

write-host -NoNewLine "`nGetting Imageprofiles, please wait ..."
$iplist = @()
if ($iZip -and !($update)) {
Get-EsxImageprofile -Softwaredepot $basedepot | foreach { $iplist += $_ }
} else {
if ($v67) {
Get-EsxImageprofile "ESXi-6.7*" -Softwaredepot $basedepot | foreach { $iplist += $_ }
} else {
if ($v65) {
Get-EsxImageprofile "ESXi-6.5*" -Softwaredepot $basedepot | foreach { $iplist += $_ }
} else {
if ($v60) {
Get-EsxImageprofile "ESXi-6.0*" -Softwaredepot $basedepot | foreach { $iplist += $_ }
} else {
if ($v55) {
Get-EsxImageprofile "ESXi-5.5*" -Softwaredepot $basedepot | foreach { $iplist += $_ }
} else {
if ($v51) {
Get-EsxImageprofile "ESXi-5.1*" -Softwaredepot $basedepot | foreach { $iplist += $_ }
} else {
if ($v50) {
Get-EsxImageprofile "ESXi-5.0*" -Softwaredepot $basedepot | foreach { $iplist += $_ }
} else {
# Workaround for http://kb.vmware.com/kb/2089217
Get-EsxImageprofile "ESXi-5.0*" -Softwaredepot $basedepot | foreach { $iplist += $_ }
Get-EsxImageprofile "ESXi-5.1*" -Softwaredepot $basedepot | foreach { $iplist += $_ }
Get-EsxImageprofile "ESXi-5.5*" -Softwaredepot $basedepot | foreach { $iplist += $_ }
Get-EsxImageprofile "ESXi-6.0*" -Softwaredepot $basedepot | foreach { $iplist += $_ }
Get-EsxImageprofile "ESXi-6.5*" -Softwaredepot $basedepot | foreach { $iplist += $_ }
Get-EsxImageprofile "ESXi-6.7*" -Softwaredepot $basedepot | foreach { $iplist += $_ }
}
}
}
}
}
}
}

if ($iplist.Length -eq 0) {
write-host -ForegroundColor Red " [FAILED]`n`nFATAL ERROR: No valid Imageprofile(s) found!"
if ($iZip) {
write-host -ForegroundColor Red "The input file is probably not a full ESXi base bundle.`n"
}
exit
} else {
write-host -ForegroundColor Green " [OK]"
$iplist = @( $iplist | Sort-Object -Descending -Property @{Expression={$_.Name.Substring(0,10)}},@{Expression={$_.CreationTime.Date}},Name )
}

# if -sip then display menu of available image profiles ...
if ($sip) {
if ($update) {
write-host "`nSelect Imageprofile to use for update:"
} else {
write-host "`nSelect Base Imageprofile:"
}
write-host "-------------------------------------------"
for ($i=0; $i -lt $iplist.Length; $i++ ) {
write-host ($i+1): $iplist[$i].Name
}
write-host "-------------------------------------------"
do {
$sel = read-host "Enter selection"
if (isNumeric $sel) {
if (([int]$sel -lt 1) -or ([int]$sel -gt $iplist.Length)) { $sel = $null }
} else {
$sel = $null
}
} until ($sel)
$idx = [int]$sel-1
} else {
$idx = 0
}
if ($update) {
$updIP = $iplist[$idx]
} else {
$CloneIP = $iplist[$idx]
}

write-host ("`nUsing Imageprofile " + $CloneIP.Name + " ...")
write-host ("(dated " + $CloneIP.CreationTime + ", AcceptanceLevel: " + $CloneIP.AcceptanceLevel + ",")
write-host ($CloneIP.Description + ")")

# If customization is required ...
if ( ($pkgDir -ne "") -or $update -or ($load -ne @()) -or ($remove -ne @()) ) {

# Create your own Imageprofile
if ($ipname -eq "") { $ipname = $CloneIP.Name + "-customized" }
if ($ipvendor -eq "") { $ipvendor = $CloneIP.Vendor }
if ($ipdesc -eq "") { $ipdesc = $CloneIP.Description + " (customized)" }
$MyProfile = New-EsxImageprofile -CloneProfile $CloneIP -Vendor $ipvendor -Name $ipname -Description $ipdesc

# Update from Online depot profile
if ($update) {
write-host ("`nUpdating with the VMware Imageprofile " + $UpdIP.Name + " ...")
write-host ("(dated " + $UpdIP.CreationTime + ", AcceptanceLevel: " + $UpdIP.AcceptanceLevel + ",")
write-host ($UpdIP.Description + ")")
$diff = Compare-EsxImageprofile $MyProfile $UpdIP
$diff.UpgradeFromRef | foreach {
$uguid = $_
$uvib = Get-EsxSoftwarePackage | where { $_.Guid -eq $uguid }
write-host -nonewline " Add VIB" $uvib.Name $uvib.Version
AddVIB2Profile $uvib
}
}

# Loop over Offline bundles and VIB files
if ($pkgDir -ne "") {
write-host "`nLoading Offline bundles and VIB files from" $pkgDir ...
foreach ($obundle in Get-Item $pkgDir\*.zip) {
write-host -nonewline " Loading" $obundle ...
if ($ob = Add-EsxSoftwaredepot $obundle -ErrorAction SilentlyContinue) {
write-host -ForegroundColor Green " [OK]"
$ob | Get-EsxSoftwarePackage | foreach {
write-host -nonewline " Add VIB" $_.Name $_.Version
AddVIB2Profile $_
}
} else {
write-host -ForegroundColor Red " [FAILED]`n Probably not a valid Offline bundle, ignoring."
}
}
foreach ($vibFile in Get-Item $pkgDir\*.vib) {
write-host -nonewline " Loading" $vibFile ...
try {
$vib1 = Get-EsxSoftwarePackage -PackageUrl $vibFile -ErrorAction SilentlyContinue
write-host -ForegroundColor Green " [OK]"
write-host -nonewline " Add VIB" $vib1.Name $vib1.Version
AddVIB2Profile $vib1
} catch {
write-host -ForegroundColor Red " [FAILED]`n Probably not a valid VIB file, ignoring."
}
}
}
# Load additional packages from Online depots or Offline bundles
if ($load -ne @()) {
write-host "`nLoad additional VIBs from Online depots ..."
for ($i=0; $i -lt $load.Length; $i++ ) {
if ($ovib = Get-ESXSoftwarePackage $load[$i] -Newest) {
write-host -nonewline " Add VIB" $ovib.Name $ovib.Version
AddVIB2Profile $ovib
} else {
write-host -ForegroundColor Red " [ERROR] Cannot find VIB named" $load[$i] "!"
}
}
}
# Remove selected VIBs
if ($remove -ne @()) {
write-host "`nRemove selected VIBs from Imageprofile ..."
for ($i=0; $i -lt $remove.Length; $i++ ) {
write-host -nonewline " Remove VIB" $remove[$i]
try {
Remove-EsxSoftwarePackage -ImageProfile $MyProfile -SoftwarePackage $remove[$i] | Out-Null
write-host -ForegroundColor Green " [OK]"
} catch {
write-host -ForegroundColor Red " [FAILED]`n VIB does probably not exist or cannot be removed without breaking dependencies."
}
}
}

} else {
$MyProfile = $CloneIP
}


# Build the export command:
$cmd = "Export-EsxImageprofile -Imageprofile " + "`'" + $MyProfile.Name + "`'"

if ($ozip) {
$outFile = "`'" + $outDir + "\" + $MyProfile.Name + ".zip" + "`'"
$cmd = $cmd + " -ExportTobundle"
} else {
$outFile = "`'" + $outDir + "\" + $MyProfile.Name + ".iso" + "`'"
$cmd = $cmd + " -ExportToISO"
}
$cmd = $cmd + " -FilePath " + $outFile
if ($nsc) { $cmd = $cmd + " -NoSignatureCheck" }
$cmd = $cmd + " -Force"

# Run the export:
write-host -nonewline ("`nExporting the Imageprofile to " + $outFile + ". Please be patient ...")
if ($test) {
write-host -ForegroundColor Yellow " [Skipped]"
} else {
write-host "`n"
Invoke-Expression $cmd
}

write-host -ForegroundColor Green "`nAll done.`n"

# The main catch ...
} catch {
write-host -ForegroundColor Red ("`n`nAn unexpected error occured:`n" + $Error[0])
write-host -ForegroundColor Red ("`nIf requesting support please be sure to include the log file`n " + $log + "`n`n")

# The main cleanup
} finally {
cleanup
if (!($PSBoundParameters.ContainsKey('log')) -and $PSBoundParameters.ContainsKey('outDir')) {
$finalLog = ($outDir + "\" + $MyProfile.Name + "-" + (get-date -Format yyyyMMddHHmm) + ".log")
Move-Item $log $finalLog -force
write-host ("(Log file moved to " + $finalLog + ")`n")
}
}
点击此处 ← 查看帮助
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
PS D:\yuangezhizao\Documents\ESXi> .\ESXi-Customizer-PS-v2.6.0.ps1 -help

This is ESXi-Customizer-PS Version 2.6.0 (visit https://ESXi-Customizer-PS.v-front.de for more information!)

Usage:
ESXi-Customizer-PS [-help] | [-izip <bundle> [-update]] [-sip] [-v67|-v65|-v60|-v55|-v51|-v50]
[-ozip] [-pkgDir <dir>] [-outDir <dir>] [-vft] [-dpt depot1[,...]]
[-load vib1[,...]] [-remove vib1[,...]] [-log <file>] [-ipname <name>]
[-ipdesc <desc>] [-ipvendor <vendor>] [-nsc] [-test]

Optional parameters:
-help : display this help
-izip <bundle> : use the VMware Offline bundle <bundle> as input instead of the Online depot
-update : only with -izip, updates a local bundle with an ESXi patch from the VMware Online depot,
combine this with the matching ESXi version selection switch
-pkgDir <dir> : local directory of Offline bundles and/or VIB files to add (if any, no default)
-ozip : output an Offline bundle instead of an installation ISO
-outDir <dir> : directory to store the customized ISO or Offline bundle (the default is the
script directory. If specified the log file will also be moved here.)
-vft : connect the V-Front Online depot
-dpt depot1[,...] : connect additional Online depots by URL or local Offline bundles by file name
-load vib1[,...] : load additional packages from connected depots or Offline bundles
-remove vib1[,...] : remove named VIB packages from the custom Imageprofile
-sip : select an Imageprofile from the current list
(default = auto-select latest available standard profile)
-v67 | -v65 | -v60 |
-v55 | -v51 | -v50 : Use only ESXi 6.7/6.5/6.0/5.5/5.1/5.0 Imageprofiles as input, ignore other versions
-nsc : use -NoSignatureCheck with export
-log <file> : Use custom log file <file>
-ipname <name>
-ipdesc <desc>
-ipvendor <vendor> : provide a name, description and/or vendor for the customized
Imageprofile (the default is derived from the cloned input Imageprofile)
-test : skip package download and image build (for testing)

3.下载ESXi离线包

它的文件命名格式突然变了,现在的ESXi670-201912001.zip与之前的update-from-esxi6.7-6.7_update03.zip……

ESXi670-201912001
ESXi670-201912001
最新到 1205
最新到 1205

推荐一个与此强相关的网站,老管网络日志 | funpower’s blog

看来就是这个了
看来就是这个了
龟速下载
龟速下载
1
2
3
4
5
6
7
8
9
10
11
12
VMware vSphere Hypervisor (ESXi) Offline Bundle
文件大小: 451.7 MB
文件类型: zip
立即下载
Name: ESXi670-201912001.zip
发行日期: 2019-12-05
内部版本号: 15160138
VMware vSphere Hypervisor (ESXi) Offline Bundle
Including VMware Tools. Use the image profiles and the VIB packages with VMware Image BuContains VIB packages
MD5SUM: 153ea9de288d1cc2518e747f3806f929
SHA1SUM: e9761a1a8148d13af8a920decd9d729658d59f1c
SHA256SUM: a480208411422076e7cb7fda83aed2198513deb5859d6087f56f931afb0aa399

4. 下载Realtek 8168网卡驱动

Net55-r8168 - V-Front VIBSDepot Wiki可以了解到

Supported Devices / PCI IDs
10ec:8168, 1186:4300

(Realtek RTL8111B / RTL8168B / RTL8111/RTL8168 / RTL8111C / RTL8111CP / RTL8111D(L) / RTL8168C / RTL8111DP / RTL8111E / RTL8168E / RTL8111F / RTL8411 / RTL8111G / RTL8111GUS / RTL8411B(N) / RTL8118AS / D-Link DGE-528T)

下载这个:net55-r8168-8.045a-napi-offline_bundle.zip

5.封装

终于成功
终于成功
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
PS D:\yuangezhizao\Documents\ESXi> ./ESXi-Customizer-PS-v2.6.0.ps1 -izip ESXi670-201912001.zip -dpt net55-r8168-8.045a-napi-offline_bundle.zip -load net55-r8168

This is ESXi-Customizer-PS Version 2.6.0 (visit https://ESXi-Customizer-PS.v-front.de for more information!)
(Call with -help for instructions)

Logging to C:\Users\YUANGE~1\AppData\Local\Temp\ESXi-Customizer-PS-17316.log ...

Running with PowerShell version 5.1 and VMware PowerCLI version 11.5.0.14899560

Adding base Offline bundle ESXi670-201912001.zip ... [OK]

Connecting additional depot net55-r8168-8.045a-napi-offline_bundle.zip ... [OK]

Getting Imageprofiles, please wait ... [OK]

Using Imageprofile ESXi-6.7.0-20191204001-standard ...
(dated 11/25/2019 11:43:03, AcceptanceLevel: PartnerSupported,
Updates ESXi 6.7 Image Profile-ESXi-6.7.0-20191204001-standard)

Load additional VIBs from Online depots ...
Add VIB net55-r8168 8.045a-napi [New AcceptanceLevel: CommunitySupported] [OK, added]

Exporting the Imageprofile to 'D:\yuangezhizao\Documents\ESXi\ESXi-6.7.0-20191204001-standard-customized.iso'. Please be patient ...


All done.

PS D:\yuangezhizao\Documents\ESXi>

6.烧录

亲测使用balenaEtcher烧录之后的U盘并不能成功启动,于是采用官网←的rufus该工具

?
选择镜像和盘
选择镜像和盘

注意如果提示啥启动项过于老旧可能不会成功需要联网下载新版请点,第一次没截图现在不出弹提示了草

7.启动

机子搬回屋子里,菊花插上显示器、键盘和盘……开机BIOS设置项里选盘启动!

BIOS
BIOS
Installer
Installer
Enter
Enter

这里让选在哪块硬盘上安装或升级ESXi,当时一愣选错就尴尬了……
后来看到可以看详细信息,只有一块硬盘含有ESX(I) Found:ESXi 6.7.0

看硬盘详细信息
看硬盘详细信息
Upgrade
Upgrade
最终确认
最终确认
升级中
升级中
升级完成
升级完成
运行中
运行中

然后关机后把机子拿到客厅,插上电源和网线(主板上电自动开机
回到卧室,进web一看

不慌,再等等
不慌,再等等
大功告成
大功告成

挂起的macOS成功启动,并不用重新破解,看起来没什么大问题hhh,可以去睡觉了.zZ……

0x01.VMware ESXi

这玩楞就是传说中的把服务器整机都虚拟化的软件,之前用的VMware Workstation只是在本机跑虚拟机。而前者虚拟化完成之后并没有图形化界面,只能在另一台电脑上远程访问Web界面进行管理,比如创建多个虚拟机此类操作。所以,你懂得……
这里就截几个图看看吧(WZ大佬组的台式机硬件,华硕主板、E3 CPU,16G内存,唯一不足的是硬盘拿了个辣鸡500G先扛着了
2019-12-28 00:43:33该硬盘于上周已炸……
电信宽带提供公网IP,只需一个电话说明理由就给你分配,与移动的NAT相比已经很良心的了……
再一个这里能获取到IPV6地址,下列截图中也进行了高斯模糊处理干脆折叠起来好了~

host
host

这里比较有意思的是,你可以创建大于物理核心数量的虚拟核心,也可以理解为虚拟化的是总频率,如下图

CPU
CPU

更改用户权限的页面藏在了这里,找了半天才发现,实在是太反人类了……

permission
permission

web页面每900s会强制下线草,参照为 ESXi Shell 和 vSphere Web Client 设置超时可以在高级设置中修改至0

官方文档
官方文档
超时
超时
逼死强逼症患者
逼死强逼症患者

参照为 ESXi 6.0 主机配置 CA 签名证书 (2113926)

官方文档
官方文档
腾讯云申请免费证书
腾讯云申请免费证书

重命名为rui.crtrui.key,上传至/etc/vmware/ssl文件夹中

上传自己的证书
上传自己的证书

懒得重启了,于是
/etc/init.d/hostd restart/etc/init.d/vpxa restart

XShell
XShell
点击此处 ← 查看终端
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
Copyright (c) 2002 NetSarang Computer, Inc. All rights reserved.

Type `help' to learn how to use Xshell prompt.
[D:\~]$

Connecting to 192.168.25.249:22...
Connection established.
To escape to local shell, press 'Ctrl+Alt+]'.

The time and date of this login have been sent to the system logs.

WARNING:
All commands run on the ESXi shell are logged and may be included in
support bundles. Do not provide passwords directly on the command line.
Most tools can prompt for secrets or accept them from standard input.

VMware offers supported, powerful system administration tools. Please
see www.vmware.com/go/sysadmintools for details.

The ESXi Shell can be disabled by an administrative user. See the
vSphere Security documentation for more information.
[root@VM:~] cd /etc/vmware/ssl
[root@VM:/etc/vmware/ssl] ls
castore.pem rui.crt vsan_kms_client.crt vsanvp_castore.pem
iofiltervp.pem rui.key vsan_kms_client.key
openssl.cnf vsan_kms_castore.pem vsan_kms_client_old.crt
rui.bak vsan_kms_castore_old.pem vsan_kms_client_old.key
[root@VM:/etc/vmware/ssl] rm rui.crt rui.key
[root@VM:/etc/vmware/ssl] /etc/init.d/hostd restart
watchdog-hostd: Terminating watchdog process with PID 2099465
hostd stopped.
hostd started.
[root@VM:/etc/vmware/ssl] /etc/init.d/vpxa restart
watchdog-vpxa: Terminating watchdog process with PID 2099054
vpxa stopped.
vpxa started.
[root@VM:/etc/vmware/ssl]
新增内网?解析
新增内网?解析
完工爽到
完工爽到

2019-8-24 13:06:59

4TB 硬盘购买
4TB 硬盘购买
NASdata 3TB
NASdata 3TB

2019-12-28 00:19:00
旧硬盘已炸(彻底报废?)替代硬盘已上,然后开机发现web连不上……出去看机子听到硬盘一直咔咔响……
WZ大佬现身Trouble Shooting,发现那块硬盘连的是旧的SATA硬盘线,换上新的1/元根的线之后好了
猜想之前的那块系统盘坏掉的原因也可能是因为这条线,草

机子
机子
那条硬盘线
那条硬盘线

2020-4-4 22:13:12

VMware Tools Offline VIB Bundle
VMware Tools Offline VIB Bundle

0x02.后记

这玩楞搁在了客厅的冰箱旁边和冰箱一起24h不断电工作,虽然主板以及其他位置都配置为了节能,但是感觉还是会比较费电……也不知道功耗能有多少诶?

0x03.引用

旧笔记本通过自定义整合网卡驱动安装 ESXi 6.7.0 u1
命令行操作vSphere–VMware PowerCLI安装
【下载】VMware vSphere 7.0 正式版
升级ESXI到最新的6.7 U3版本
